Description
Exit lock case with automatic deadlocking latch bolt for profile doors with one blade.
Features
Finish: Fe/ ZL
The door is opened from outside with a door pull.
The lock is always opened from the inside by a lever handle, push pad or panic bar.
Handing: left
Backset : 35 mm
Not suitable for fire doors
LE315X is the microswitch version of the lock
Automatically deadlocked
Applications:
Evacuation doors
Profile doors
Deadlocking is controlled by a snib in the front plate. Using of the snib is normally blocked. The snib is released by turning the key.
Snib position:
UP = Deadlocked. The lock can be opened from outside by key only and from inside by a lever handle, push pad or panic bar.
DOWN = Latch bolt is retained inside the lock case.
